C4 Suspension Swaps

Getting the Perfect Fit: Specifying Van Steel C4 Coilovers for Your Custom Chassis

Swapping a C4 Corvette suspension into a custom chassis is a fantastic way to upgrade the handling and stance of your project. Because custom frames vary wildly in their geometry and weight distribution, a "one-size-fits-all" coilover kit isn't always the right answer.

If your rear spring looks like the image below and/or your front spring is perfectly flat...coilovers are a great solution if you have the clearance.

Rear C4 Composite spring not holding up weight

At Van Steel, we want to ensure your coilover kit performs flawlessly right out of the box. To determine if our standard C4 coilover kits will work—or if you need custom spring rates and shock lengths—we need a few specific details and measurements. Here is exactly what to look for and measure before placing your order.

1. Identify Your C4 Suspension Generation

Chevrolet made significant updates to the C4 suspension during its run. We need to know whether you are working with an Early (1984–1987) or Late (1988–1996) setup.

Front Lower Control Arms:

Early (84–87): Features a bolt-on aluminum plate. The shock and the sway bar end link both mount directly to this plate.
Late (88–96): The shock bolts directly to the control arm itself, and the lower sway bar mount is located on the front side of the arm.

Rear Suspension:

Early (84–87): Identifiable by internal parking brake shoes inside the rotor, OR a lower shock mount stud that angles downward.
Late (88-96): The parking brake cable bolts directly to the caliper and uses the brake pads as a parking brake.

2. Document Your Upper Mounts And Clearances

Because you are using a custom chassis, the upper shock mounts in both the front and rear could be designed in several different ways. This can also create clearance issues converting from a smooth body shock to a threaded coilover. Our coilover springs are 3.25" OD.

Action Required: Snap a few clear photos of your front and rear upper mounts and submit them to the Van Steel team (email vettes@vansteel.com or text our 727 number). This allows us to supply the correct mounting hardware or adaptors.
Check shock clearances: The rear is the most common to have issues with as the upper shock mount will be mounted too far rearward for the coil spring to clear the half shaft. See image below.

3. Vehicle Specifications & Weight

To calculate the correct spring rate for your coilovers, we need to know the mass they will be supporting.

Body Style: What kind of vehicle body is sitting on the frame? (e.g., C1 Corvette, 1955 Chevy truck, custom hot rod).
Total Weight: The total curb weight of the vehicle.
Weight Distribution (Bonus): If you have access to four-corner scales, providing the separated front and rear weights will yield the most accurate spring rate calculation possible, especially for trucks.
Stance Goals: Do you plan to raise or lower the vehicle from its current stance?

4. The Critical Measurement: Shock Length at Ride Height

This is the most important step. We need the exact distance between the upper and lower shock mounts at your preferred ride height.

How to get this measurement:

Remove the existing shocks and transverse leaf springs from the chassis.
With the suspension free to move, use a lift, jacks, or blocks to raise or lower the chassis until the vehicle is sitting at your exact desired ride height.
Once the stance is set, use a tape measure to find the exact distance between the center of the upper shock mount and the center of the lower shock mount.
Record this measurement for both the front and the rear.

Visualizing the Measurement (Diagram)

Below is a basic reference diagram showing exactly where to pull your measurements from. You can use this concept to record your dimensions before contacting us.

Plaintext

       CUSTOM CHASSIS FRAME
====================================
               |
         [Upper Mount]
              (O) <----- Measure from the center of the upper mount
               |         (eyelet hole or stud)
               |
               | <------ REQUIRED DIMENSION
               |         Distance between mounts at
               |         your PREFERRED ride height.
               |
              (O) <----- Measure to the center of the lower mount
         [Lower Mount]   (eyelet hole or stud)
               |
====================================
    LOWER CONTROL ARM / KNUCKLE

Checklist for Your Van Steel Order:

[ ] Suspension Year (84-87 or 88-96) verified via Front LCAs / Rear Hubs
[ ] Photos of Front and Rear custom upper chassis mounts
[ ] Vehicle body style and stance goals (raise/lower)
[ ] Total vehicle weight (Front/Rear bias if possible)
[ ] Front measurement: Upper to lower mount distance at ride height
[ ] Rear measurement: Upper to lower mount distance at ride height

Gather this information, send it over to the Van Steel team along with your upper mount photos, and we will get to work building the perfect coilover package tailored to your custom chassis.
